Sunex Fish S4 x 100 liter suspension or setting feet

Water buffer tank Sunex Fish S4 X – 100 liters

Product overview

The Sunex Fish S4 X is a 100 liter buffer tank for vertical operation. It is available in a hanging or standing version and was specially developed for use in modern heating systems.

Ideal for all types of heating systems, especially in combination with heat pumps. The buffer tank enables the connection of a heat source circuit and a central heating circuit, thus optimizing system operation.

Function & Temperature range

The memory is used to temporarily store thermal energy to shift the load and adjust the performance of heating systems. In addition, it can be used for cooling: storage of cooling water at temperatures between 7 and 12 °C is possible.

The buffer tank is designed exclusively for vertical installation. When installing, ensure there is a stable surface or suitable suspension and allow for sufficient space for connections and maintenance.

Advantages

The Sunex Fish S4

Technical data

hanging version

• Material: S235JR
• Maximum operating pressure of the accumulator: 3 bar
• Operating temperature range: 7÷95º C
• Insulation: 29 mm
• Consumer/heat source connections: IG 1½”
• Temp. sensor connections: IG ½”

standing version

• Material: S235JR
• Maximum operating pressure of the accumulator: 3 bar
• Operating temperature range: 7÷95º C
• Insulation: 30 mm
• Consumer/heat source connections: G 1½”
• Temp. sensor connections: G ½”
